| Image Sensor |
|---|
| Shape | Box, |
|---|
| Sensor | CMOS, |
|---|
| Sensor Size | 1/4 Inch Color CMOS Sensor, |
|---|
| Effective Pixels | 1.3 MP, |
|---|
| Lens (mm) | IR Lens,f=3.6mm，F=2.0, |
|---|
| Lens | Prime, |
|---|
| Lens + | IR-cut,Day Night, |
|---|
| Minimum Illumination (Lux) | IR LED on,0 Lux, |
|---|
| Viewing Angle (°) | 75, |
|---|
| Video Image/Audio Setting |
|---|
| Compression | H.264, |
|---|
| Video Frame Rate (FPS) | 30, |
|---|
| Refresh Rate | 60HZ,50HZ, |
|---|
| Video Adjustment | Auto Backlight Compensation,Auto White Balance,Contrast Adjustable,Brightness Adjustable, |
|---|
| Audio Output | Built-in Speaker, |
|---|
| Audio Input | Built-in Mic, |
|---|
| Audio Compression Standard | G711A, |
|---|
| Communication&Interface |
|---|
| Connection Mode | Wireless,Wired, |
|---|
| Network Interface | RJ-45 10/100Mb self-adaptable Ethernet slot,Wi-Fi/802.11/b/g, |
|---|
| Supported Protocol | PPPoE,UPNP,DDNS,HTTP,SMTP,DHCP,TCP/IP,FTP, |
|---|
| P2P | yes, |
|---|
| Wireless Security | WPA2,WPA, |
|---|
| IP Mode | Static IP address,Dynamic IP address, |
|---|
| DDNS (Free) | Yes, |
|---|
| Alarm Action | Email Photo,FTP Photo,Local Alarm, |
|---|
| Physical/Environment |
|---|
| Home | Baby Room, |
|---|
| Business | School,Warehouse,Store,Office, |
|---|
| Environment | Indoor, |
|---|
| Power Supply (V) | 5V, 1.5A, |
|---|
| Power Consumption (W) | <6W, |
|---|
| Operate Temperature (℃) | －10°C~＋50°C, |
|---|
| Storage Temperature (℃) | －20°C~＋60°C, |
|---|
| Humidity (%) RH | 10% - 80%, |
|---|
| Size (L x H x W, mm) | 60*70*130mm, |
|---|
| Weight (g) | 0.15, |
|---|
| System Requirment |
|---|
| Supported Mobile Systems | Android,iPhone OS, |
|---|
| Supported Operating Systems | Microsoft Windows 7,Microsoft Windows Vista,Microsoft Windows XP,Microsoft Windows 2000,Microsoft Windows 98,Mac os, |
|---|
| Supported Browser | Google Chrome,Firefox,Safari,IE, |
|---|
| Client Software | Yes, |
|---|
| Additional Features |
|---|
| IR Distance | 10-15M, |
|---|
| Languages | Spanish,English,Dutch,Italian,Traditional Chinese,Simplified Chinese,Japanese,Russian, |
|---|
| Features | Motion Detection,Day Night,Plug and play,Wi-Fi Protected Setup,IR-cut,Remote Access,Dual Stream, |
|---|
| HDD Recording Function | Yes, |
|---|
| Two-way Radio | No, |
|---|
| Voice call | Two-Way Audio, |
|---|
| Storage | TF Card,Cloud, |
|---|
| Maximum SD Card Support (GB) | 32, |
|---|
| Other Function | Dual Stream, |
|---|
| Online User | >10, |
|---|
| Update Firmware | Yes, |
|---|
| Brand | Factory-OEM, |
|---|
| General |
|---|
| What's in the box | Bracket,English User manual,CD,Wi-Fi anntena,Ethernet cable,Screew,Power adaptor,IP camera, |
|---|
